Huawei MA5800 X2
Huawei MA5800-X2 Optical Line Terminal (OLT)
Next-generation optical line terminal (NG-OLT) with 40 Gbit/s throughput. Huawei’s multi-service access module uses a distributed architecture to support ultra-broadband services, fixed-mobile convergence (FMC), and intelligent functions such as SDN-based virtualization. The MA5800′s programmable network processor (NP) accelerates the introduction of new services, meeting the demands of diverse services, including wholesale and retail service provider divisions.
Build a broader, faster, and smarter access network for a better business experience
The ultra-broadband optical network supports fixed-mobile convergence (FMC) and SDN-based intelligent services. Each service slot delivers 200 Gbit/s throughput, ensuring non-blocking access for high-density XG-PON and 40G-PON networks. Each subrack supports up to 32,000 users at 100 Mbit/s, enabling seamless 4K video viewing. Full-service PON/P2P access for home, business, and mobile backhaul creates a single optical network with FMC services.
In recent years, new trends in broadband services have emerged, requiring access networks to be larger, faster, and more intelligent. The MA5800-X2 distributed switching architecture enables the construction of a high-bandwidth, non-blocking system. Thanks to its flexibility and scalability, operators can gradually increase the data exchange capacity of the OLT system based on the growth of user services, and confidently cope with future data influx and countless new industries.
Specification
Specification
Switching capacity
480 Gbit/s
Address table size
262 entries
Route entries
64000
Switching layer
L2/L3
Number of GPON ports
32
Number of 10G-PON ports
16
Number of GE/FE ports
96
Number of E1 ports
64
Number of 10G Ethernet ports
16
Routing protocols
BGP,BGP4,IS-IS,OSPF,OSPFv3,RIP
Communication protocol
ARP
AC input voltage
100/240 V
DC voltage range
-38.4 – 72 V
Dimensions (mm): length / depth / height
442 mm x 268.7 mm x 88.1 mm
